4V
|
1
|
10
|
/
|
06
|
AC110V
|
|
kŘkohu kiko'ī
|
Helu helu
|
Coil a me nā kūlana
|
|
Hoʻohui i ka nui o ka paipu
|
Voltage
|
|
5 ala 2(3) kūlanasolenoid valve
|
1:100 moʻo
|
10:2/5 ala hoʻokahi 2 kūlana
|
|
M5:M5x0.8
|
DC12V
|
|
|
|
20:2/5 2 poʻo 2 kūlana
|
|
06:1/8"
|
DC24V
|
|
|
|
30C:3/5 2 poʻo 3 kūlana sila ʻano
|
|
|
AC24V50/60HZ
|
|
|
|
30E:3/5 2 poʻo 3 kūlana ʻano hoopau
|
|
|
AC110V50/60Hz
|
|
|
|
30P:3/5 2 poʻo 3 kūlana ʻano kaomi
|
|
|
AC220V50/60Hz
|
|
|
|
|
|
|
AC380V50/60Hz
|
|
Hoʻohālike
|
4V130C-06 DC24V
|
4V130C-M5 DC24V
|
4V130C-06 AC 220V
|
4V130C-M5 AC 220V
|
|
|
4V130E-06 DC24V
|
4V130E-M5 DC24V
|
4V130E-06 AC 220V
|
4V130E-M5 AC 220V
|
||
|
4V130P-06 DC24V
|
4V130P-M5 DC24V
|
4V130P-06 AC 220V
|
4V130P-M5 AC 220V
|
||
|
ʻAno hana
|
Ea
|
||||
|
ʻAno hana
|
Pilota kūloko
|
||||
|
Nā kūlana
|
5 ala 2 kūlana
|
5 ala 3 kūlana
|
5 ala 3 kūlana
|
/
|
|
|
Kea kūpono- 10mm-(CV=0.56) 7mm2(CV=0.40) māhele ʻāpana (mm²)
|
10mm-(CV=0.56)
|
7mm2(CV=0.40)
|
12mm-(CV=0.67)
|
/
|
|
|
aila lubrication
|
ʻAʻole pono
|
||||
|
Paʻi
|
1.5~8.0kgf/cm²
|
||||
|
Paʻa paʻi kiʻekiʻe
|
10.5kgf/cm2
|
||||
|
Hana wela
|
5~60 degere
|
||||
|
Laulā uila
|
+/-10%
|
||||
|
hoʻohana mana
|
AC:1.3W DC:1.5W
|
||||
|
Hoʻomākaʻi
|
F pae
|
||||
|
Pae palekana
|
IP65(DIN40050)
|
||||
|
ʻAno pili
|
Puke pololei a i ʻole ke ʻano hoʻopau
|
||||
|
Max hana alapinepine
|
5 manawa i kekona
|
||||
|
ʻO ka manawa hoʻonanea pōkole loa
|
0.05 kekona
|
||||
|
Mea ʻāpana
|
Kino
|
Aluminum huila
|
|||
|
Hoʻopaʻa i ke apo NBR
|
NBR
|
||||
Nā hiʻohiʻona:
1. Efficient and durable , hoʻonoho maʻalahi, ola lōʻihi
2. High quality alumini valve core me ka maikaʻi sealing mea, kū'ē i ka lawelawe ola, oi aku mamua o 30 miliona,
3. keia mau moʻo ea mana kiwikā ua kūpono no ka hana pālua a hoʻokahi hana cylinders i ka pneumatic mana nenoaiu.
4. He koho nā kala like ʻole no ke kino.
5. ʻO nā ana kūpono a me nā hiʻohiʻona maikaʻi
6. Loaʻa me nā mana hoʻokahi a me nā ʻāpana ʻelua
7. Coil & Connector kuai kaawale 8. Loaʻa nā lepili kiko'ī o ka mea kūʻai ma ke noi.
Nā huahana pale: 4v130p-m5 ac 220v airtec 4v130 pneumatic solenoid valve, Kina, nā mea hoʻolako, mea hana, hale hana, maʻamau, kūʻai nui
